CUSTOMER-ORIENTED
 |
| Size: | |
|---|---|
| Color: | |
| Material: | |
| Quantity: | |
LS012
Liansheng
012
| Place of Origin | Jiangsu, China |
| Brand Name | Liansheng |
| Product Name | Wholesale Truss Aluminum LED Screen Lighting Truss Display Customized Top Design Event Stage Platform |
| Material | Aluminum Alloy /Plywood |
| Stage size | 1.22mxx1.22m,1.22mx2.44m |
| Adjustable Height | 0.4-0.6m, 0.6-0.8-1.0m, 0.8-1.0-1.2m |
| Loading capacity | 750 kgs/sqm |
| Certification | CE,ISO,TUV |
| Application | Events, Party, Concert, Exhibiton, School, Wedding,etc. |
| Feature | adjustable legs, anti-rust,mobile,portable |
| Selling Units: | Single item |
| Single package size: | 60X60X60 cm |
| Single gross weight: | 10.000 kg |
| Package Type: | aluminum layher stage can be packaged by standard export box or standard wooden box |
Introduction to truss structure
Truss structure refers to truss beam, which is a beam structure with lattice structure. Truss structures are widely used in large-span buildings, exhibition halls, stadiums, bridges and other public buildings. Because they are mostly used to build roofs, trusses are often called roof trusses.
The stress in each member is mainly unidirectional tension and compression. By rationally arranging the upper and lower chords and web members, the bending moment and shear force distribution of the structure can be adapted. Due to the balance of internal forces of tension and compression in the horizontal direction, the entire structure will not produce horizontal thrust on the support. Flexible layout and wide range of applications. In terms of bending resistance, since the tension and compression sections are concentrated at the upper and lower ends, the internal moment arm increases, making the bending strength of the truss beam greater than that of the web beam. In terms of shear resistance, through reasonable arrangement of web rods, shear force can be gradually transmitted to the bearings. In this way, it is both bending and shear resistant, and the truss structure can make full use of the material strength, making it suitable for roof structures of various spans. More importantly, it converts the complex stress state of solid web beams under transverse bending into the simple tension-compression stress state of truss members, so that the distribution and transmission of force can be intuitively understood and facilitated changes. and combined with structure
Please contact us to discuss with shipping cost for Different country and different Area Please Notice our price is For Fixed Size
Product Parameters
| Length | 2 Meters(6.56ft) |
| Outer Diameter tube | 2 in (50mm).Diameter:11.42*11.42 in (290*290mm) |
| Diagonal bracing | 0.15 in(20mm),Centerpoint load:4,568 1bs(2,072kg) |
| Distributed load | 6,093 1bs (2,764kg) |
| Wall thickness | 0.08 in (2mm).Weight:26.451bs(12kg) |
| Approvals | TUV,CE,SGS |
Aluminum Alloy 6061-T6/6082-T6
| Main Tube | Vice Tube | Brace Tube |
| 50*4mm/50*3mm | 50*2mm/30*2mm | 20*2mm/25*2mm/30*2mm |
